Nason >> Nason Piston & pin set - 4P1299-0.50

Nason Piston & pin set - 4P1299-0.50

Part
Nason logo

Nason Piston & pin set - 4P1299-0.50

Out Of Stock

Specifications
Piston Set: 4 x Piston & Pins
Std Bore Size: 77.60mm
Size: 0.50mm / .020"
Head Type: Dome Top
Piston Type: Cast
Length: 55.75mm
Comp Height: 31.30mm + 2.45mm
Size: 0.50mm Oversize
Ring Set: 2C5218
Oil Ring Width: 2.00mm
2nd Ring Width: 1.50mm
Top Ring Width: 1.20mm
Piston to Bore: See Label on Box
Skirt Coating: No
Pin Type: Press Fit
Pin Size: 18.00mm x 55.00mm
