Nason Piston & pin set - 4P1373-1.00

Part

Nason Piston & pin set - 4P1373-1.00

Out Of Stock

Specifications
2nd Ring Width:	1.50mm
Oil Ring Width:	2.80mm
Ring Set:	2C4780
Size:	1.00mm Oversize
Top Ring Width:	1.20mm
Piston to Bore:	See Label on Box
Skirt Coating:	No
Pin Type:	Press Fit
Pin Size:	22.00mm x 62.00mm
Comp Height:	34.70mm - 2.00mm
Length:	66.70mm
Piston Type:	Cast
Head Type:	Dish Top With 4 Valve Reliefs
Size:	1.00mm / .040"
Std Bore Size:	86.50mm
Piston Set:	4 x Piston & Pins
