Nason >> Nason Piston & pin set - 4P1375-1.00

Nason Piston & pin set - 4P1375-1.00

Part
Nason logo

Nason Piston & pin set - 4P1375-1.00

Out Of Stock

Specifications
Size: 1.00mm Oversize
Ring Set: 2M6193 or 6193
Oil Ring Width: 4.00mm
2nd Ring Width: 1.75mm
Top Ring Width: 1.50mm
Piston to Bore: See Label on Box
Skirt Coating: No
Pin Type: Press Fit
Pin Size: 23.00mm x 70.00mm
Comp Height: 40.00mm - 2.30mm
Length: 72.00mm
Piston Type: Cast
Head Type: Dish Top With 2 Valve Reliefs
Size: 1.00mm / .040"
Std Bore Size: 84.80mm
Piston Set: 4 x Piston & Pins

Description

Dish Top with 2 Valve Reliefs
