Nason >> Nason Piston & pin set - 4P1394-0.50

Nason Piston & pin set - 4P1394-0.50

Part
Nason logo

Nason Piston & pin set - 4P1394-0.50

Out Of Stock

Specifications
Ring Set: 4732
Oil Ring Width: 5/32"
3rd Ring Width: 1/16"
2nd Ring Width: 1/16"
Top Ring Width: 1/16"
Piston to Bore: See Label on Box
Skirt Coating: No
Pin Type: Full Floating
Pin Size: 15.86mm x 55.50mm
Comp Height: 34.09mm - 4.90mm
Length: 65.77mm
Piston Type: Cast
Head Type: Dish Top
Size: 0.50mm / .020"
Std Bore Size: 64.56mm
Piston Set: 4 x Piston & Pins
