Nason >> Nason Piston & pin set - 4P1396-1.50

Nason Piston & pin set - 4P1396-1.50

Part
Nason logo

Nason Piston & pin set - 4P1396-1.50

Out Of Stock

Specifications
Piston Set: 4 x Piston & Pins
Std Bore Size: 70.62mm
Size: 1.50mm / .060"
Head Type: Dish Top
Piston Type: Cast
Length: 58.74mm
Comp Height: 38.80mm - 5.70mm
Pin Size: 20.64mm x 55.20mm
Pin Type: Press Fit
Skirt Coating: No
Piston to Bore: See Label on Box
Top Ring Width: 1.50mm
2nd Ring Width: 1.50mm
Oil Ring Width: 3.00mm
Ring Set: 4355
