Nason >> Nason Piston & pin set - 4P1405-STD

Nason Piston & pin set - 4P1405-STD

Part
Nason logo

Nason Piston & pin set - 4P1405-STD

Out Of Stock

Specifications
Piston Set: 4 x Piston & Pins
Std Bore Size: 80.50mm
Size: Std
Head Type: Dome Top with 4 Valve Reliefs
Piston Type: Cast
Length: 51.30mm
Comp Height: 33.20mm
Pin Size: 20.00mm x 50.00mm
Pin Type: Full Floating
Skirt Coating: Yes
Piston to Bore: See Label on Box
Top Ring Width: 1.20mm
2nd Ring Width: 1.00mm
Oil Ring Width: 2.00mm
Ring Set: 2C5395

Description

Anodized Head, Top & 2nd Ring Lands
