Nason Piston & pin set - 4P1407-0.50

Part

Nason Piston & pin set - 4P1407-0.50

Out Of Stock

Specifications
Piston Set:	4 x Piston & Pins
Std Bore Size:	84.00mm
Size:	0.50mm / .020"
Head Type:	Dome Top with 4 Valve Reliefs
Piston Type:	Cast
Length:	53.00mm
Comp Height:	31.30mm + 3.10mm
Pin Size:	20.00mm x 53.00mm
Pin Type:	Full Floating
Skirt Coating:	Yes
Piston to Bore:	See Label on Box
Top Ring Width:	1.20mm
2nd Ring Width:	1.20mm
Oil Ring Width:	2.00mm
Ring Set:	2C5223
Size:	0.50mm Oversize

Description

Anodized Head
