Nason >> Nason Piston & pin set - 4P1409-0.50

Nason Piston & pin set - 4P1409-0.50

Part
Nason logo

Nason Piston & pin set - 4P1409-0.50

$408.62

Specifications
Piston Set: 4 x Piston & Pins
Std Bore Size: 92.00mm
Size: 0.50mm / .020"
Head Type: Dish Top with 2 Valve Reliefs
Piston Type: Cast
Length: 51.20mm
Comp Height: 30.70mm - 0.90mm
Pin Size: 21.00mm x 58.00mm
Pin Type: Full Floating
Skirt Coating: Yes
Piston to Bore: See Label on Box
Top Ring Width: 1.20mm
2nd Ring Width: 1.00mm
Oil Ring Width: 2.00mm
Ring Set: 2C4358

Description

Anodized Head, Top & 2nd Ring Lands
