Nason Piston & pin set - 4P1424-0.50

Part

Nason Piston & pin set - 4P1424-0.50

Out Of Stock

Specifications
Piston Set:	4 x Piston & Pins
Std Bore Size:	73.60mm
Size:	0.50mm / .020"
Head Type:	Dish Top
Piston Type:	Cast
Length:	55.20mm
Comp Height:	32.60mm - 4.00mm
Pin Size:	19.00mm x 50.00mm
Pin Type:	Full Floating
Skirt Coating:	No
Piston to Bore:	See Label on Box
Top Ring Width:	1.50mm
2nd Ring Width:	1.50mm
Oil Ring Width:	2.80mm
Ring Set:	2C4158
Size:	0.50mm Oversize
