Nason Piston & pin set - 6DP2020-STD

Specifications
Piston Set:	6 x Pistons & Pins
Std Bore Size:	94.00mm
Size:	Std
Head Type:	Clover Leaf Combustion Relief
Piston Type:	Cast
Length:	80.70mm
Comp Height:	49.70mm, -1.60mm
Pin Size:	33.00mm x 73.00mm
Pin Type:	Full Floating
Skirt Coating:	No
Piston to Bore:	See Label on Box
Top Ring Width:	2.00mm Half Keystone
2nd Ring Width:	2.00mm
Oil Ring Width:	4.00mm
Ring Set:	35898-STD

Description

Suits Turbo Upgrade - (33mm Pin)

Combustion Bowl OD

Alfin Insert
