Nason >> Nason Piston & pin set - 6DP2059-0.50

Nason Piston & pin set - 6DP2059-0.50

Part
Nason logo

Nason Piston & pin set - 6DP2059-0.50

Out Of Stock

Specifications
Piston Set: 6 x Pistons & Pins
Std Bore Size: 96.00mm
Size: 0.50mm / .020"
Head Type: Clover Leaf
Piston Type: Cast
Length: 87.00mm
Comp Height: 50.20mm, -0.80mm, -1.70mm
Pin Size: 30.00mm x 80.00mm
Pin Type: Full Floating
Skirt Coating: No
Piston to Bore: See Label on Box
Top Ring Width: 2.50mm Half Keystone
2nd Ring Width: 2.00mm
Oil Ring Width: 3.00mm
Ring Set: 34160-0.50

Description

Turbo Intercooled

Combustion Bowl OD

Alfin Insert, Oil Gallery Coolin

Replaces PKNTD42TI-A-0.50
