Nason >> Nason Piston & pin set - 6P1077-1.00

Nason Piston & pin set - 6P1077-1.00

Part
Nason logo

Nason Piston & pin set - 6P1077-1.00

Out Of Stock

Specifications
Piston Set: 6 x Piston & Pins
Std Bore Size: 94.00mm
Size: 1.00mm / .040"
Head Type: Dome Top
Piston Type: Cast
Length: 79.50mm
Comp Height: 37.50mm + 0.30mm
Pin Size: 22.00mm x 75.00mm
Pin Type: Full Floating
Skirt Coating: No
Piston to Bore: See Label on Box
Top Ring Width: 1.50mm
2nd Ring Width: 1.50mm
Oil Ring Width: 4.00mm
Ring Set: 2C4612 or 4612

Description

Replaces 6KRY2822
