Nason Piston & pin set - 6P1089-0.50

Part

Nason Piston & pin set - 6P1089-0.50

Out Of Stock

Specifications
Piston Set:	6 x Piston & Pins
Std Bore Size:	87.00mm
Size:	0.50mm / .020"
Head Type:	Flat Top with 2 Valve Reliefs
Piston Type:	Cast
Length:	67.00mm
Comp Height:	32.00mm
Pin Size:	21.00mm x 64.30mm
Pin Type:	Full Floating
Skirt Coating:	No
Piston to Bore:	See Label on Box
Top Ring Width:	1.50mm
2nd Ring Width:	1.50mm
Oil Ring Width:	2.80mm
Ring Set:	2M6196 or 6196
Size:	0.50mm Oversize
