Nason >> Nason Piston & pin set - 6P1171-STD

Nason Piston & pin set - 6P1171-STD

Part
Nason logo

Nason Piston & pin set - 6P1171-STD

Out Of Stock

Specifications
Piston Set: 6 x Piston & Pins
Std Bore Size: 87.50mm
Size: Std
Head Type: Dish Top with 2 Valve Reliefs
Piston Type: Cast
Length: 62.90mm
Comp Height: 34.00mm - 3.50mm
Pin Size: 21.00mm x 63.00mm
Pin Type: Press Fit
Skirt Coating: No
Piston to Bore: See Label on Box
Top Ring Width: 1.50mm
2nd Ring Width: 1.50mm
Oil Ring Width: 4.00mm
Ring Set: 2M4689 or 4689

Description

Replaces 6MKRY8014
