Nason >> Nason Piston & pin set - 6P1315-1.00

Nason Piston & pin set - 6P1315-1.00

Part
Nason logo

Nason Piston & pin set - 6P1315-1.00

Out Of Stock

Specifications
Size: 1.00mm Oversize
Ring Set: 2C6856 or 6856
Oil Ring Width: 4.00mm
2nd Ring Width: 2.00mm
Top Ring Width: 2.00mm
Piston to Bore: See Label on Box
Skirt Coating: No
Pin Type: Press Fit
Pin Size: 21.00mm x 72.00mm
Comp Height: 38.00mm
Length: 78.00mm
Piston Type: Cast
Head Type: Flat Top
Size: 1.00mm / .040"
Std Bore Size: 83.00mm
Piston Set: 6 x Piston & Pins

Description

Flat Top
