Nason >> Nason Piston & pin set - 6P1316-1.00

Nason Piston & pin set - 6P1316-1.00

Part
Nason logo

Nason Piston & pin set - 6P1316-1.00

$235.77

Specifications
Piston Set: 6 x Piston & Pins
Std Bore Size: 85.70mm
Size: 1.00mm / .040"
Head Type: Flat Top
Piston Type: Cast
Length: 94.50mm
Comp Height: 53.20mm
Pin Size: 20.64mm x 74.40mm
Pin Type: Press Fit
Skirt Coating: No
Piston to Bore: See Label on Box
Top Ring Width: 2.50mm
2nd Ring Width: 2.50mm
Oil Ring Width: 4.73mm
Ring Set: 2C5738

Description

Replaces 6KRY2654
