Nason >> Nason Piston & pin set - 6P1316-1.50

Nason Piston & pin set - 6P1316-1.50

Part
Nason logo

Nason Piston & pin set - 6P1316-1.50

Out Of Stock

Specifications
Size: 1.50mm Oversize
Ring Set: 2C5738
Oil Ring Width: 4.73mm
2nd Ring Width: 2.50mm
Top Ring Width: 2.50mm
Piston to Bore: See Label on Box
Skirt Coating: No
Pin Type: Press Fit
Pin Size: 20.64mm x 74.40mm
Comp Height: 53.20mm
Length: 94.50mm
Piston Type: Cast
Head Type: Flat Top
Size: 1.50mm / .060"
Std Bore Size: 85.70mm
Piston Set: 6 x Piston & Pins
