Nason >> Nason Piston & pin set - 6P1345-0.50

Nason Piston & pin set - 6P1345-0.50

Part
Nason logo

Nason Piston & pin set - 6P1345-0.50

$308.88

Specifications
Size: 0.50mm Oversize
Ring Set: 2M4754 or 4754
Oil Ring Width: 2.80mm
2nd Ring Width: 1.50mm
Top Ring Width: 1.50mm
Piston to Bore: See Label on Box
Skirt Coating: No
Pin Type: Full Floating
Pin Size: 21.00mm x 64.00mm
Comp Height: 32.50mm + 2.50mm
Length: 66.50mm
Piston Type: Cast
Head Type: Dome Top with 4 Valve Reliefs
Size: 0.50mm / .020"
Std Bore Size: 86.00mm
Piston Set: 6 x Piston & Pins
