Nason >> Nason Piston & pin set - 6P1349-1.00

Nason Piston & pin set - 6P1349-1.00

Part
Nason logo

Nason Piston & pin set - 6P1349-1.00

Out Of Stock

Specifications
Top Ring Width: 1.20mm
2nd Ring Width: 1.20mm
Oil Ring Width: 2.50mm
Ring Set: 2C5112
Size: 1.00mm Oversize
Piston to Bore: See Label on Box
Skirt Coating: Yes
Pin Type: Press Fit
Pin Size: 22.00mm x 58.00mm
Comp Height: 29.60mm
Length: 53.10mm
Piston Type: Cast
Head Type: Flat Top
Size: 1.00mm / .040"
Std Bore Size: 95.50mm
Piston Set: 6 x Piston & Pins

Description

Flat Top

Anodized Head, Top & 2nd Ring Lands
