Nason Piston & pin set - 8P1391-0.50

Part
Nason logo

Nason Piston & pin set - 8P1391-0.50

Out Of Stock

Specifications
Piston Set: 8 x Piston & Pins
Std Bore Size: 94.00mm
Size: 0.50mm / .020"
Head Type: Dome Top with 4 Valve Reliefs
Piston Type: Cast
Length: 55.30mm
Comp Height: 33.40mm - 6.20mm
Pin Size: 22.00mm X 56.00mm
Pin Type: Full Floating
Skirt Coating: Yes
Piston to Bore: See Label on Box
Top Ring Width: 1.20mm
2nd Ring Width: 1.20mm
Oil Ring Width: 2.00mm
Ring Set: 2C5486

Description

Anodized Head, Top & 2nd Ring Grooves
