Nason Piston & ring set - PKRNG9U-STD

Specifications
Piston Set:	4 x Pistons, Pins & Rings
Std Bore Size:	89.00mm
Size:	STD
Head Type:	Dish top with four valve reliefs
Piston Type:	Cast
Length:	83.09mm
Comp Height:	53.03mm - 5.80mm -17.58mm
Combustion Bowl OD:	43.00mm
Pin Size:	31.00mm x 65.00mm
Pin Type:	Full Floating
Skirt Coating:	Yes
Piston to Bore:	See Label on Box
Top Ring Width:	2.50mm
2nd Ring Width:	1.75mm
Oil Ring Width:	2.50mm

Description

Alfin insert, MOS2 coated skirts

Suits tapered conrods
