Nason >> Nason Sleeve - FS5001D

Nason Sleeve - FS5001D

Part
Nason logo

Nason Sleeve - FS5001D

$48.20

Specifications
Bore Dia: 80.0 / 80.03mm
Main Coller Dia: 87.40 / 875.0mm
Main Coller Height: 50.051 / 50.075mm
Outer Dia: 84.070 / 84.120mm
Total Length: 127.3mm
Top Bore Chamfer: 0.50 / 1.00mm
Angle: 12 / 18 deg
Bottom Bore Chamfer: 1.00 / 1.50mm
Angle: 12 / 18 deg
Bottom O.D Chamfer: 1.50 / 2.00mm
Angle: 12 / 18 deg
Surface Finish In Bore: Ra = 0.25 / 0.50mm

Description

Main Collar Height | 50.051 / 50.075mm
